Export Model

Icon:

---

Introduction

This command provides the ability to export the linework of any selected Built Model.  Available output formats are drawing file .dwg or .dxf.

The linework layers come from the Assign Layers command.

Users can click and navigate in the surface display window.  Middle mouse zoom/orbit.  Ctrl+Middle Moust to pan.  The view cube top right can be used for 3D orbit and reorienting the view.  Top icons can be used to set the view to Home or change display modes: drive, zoom window, dynamic zoom, pan, orbit, zoom exents.

Details

Upon selecting the command the following form is displayed:

Model	Select the design model to display and export
Format	Select the output format: - .dwg - .dxf
2D elevations	Toggle on to output only 2D (flattened) linework
Layer Prefix	Type in a prefix for layers created for the model linework
Set	Set the layer change and reset the view.
Export	Export to file.  File save form will display.

Add any notes about the output controls and any special conditions.
